Fault code quick clearing; engine fault data flow reading card; elm327 fault detector; obd 2 diagnostic reading card; vehicle information reading
1.Handheld fault diagnosis + Bluetooth APP dual operation experience, handheld and Bluetooth 2-in-one diagnostic instrument,
2.Quick clearing of the fault code, elm327 Fault detector, The OBD 2 diagnostic code reader, Vehicle information reading code card, Car battery diagnostic instrument,
3.Diesel vehicle battery diagnostic instrument, Motorcycle / yacht battery diagnostic machine, Automotive diagnostic tool, Gas machine fault detector,
4.Diesel vehicle fault detector, battery voltage detection, OBD 2 fault diagnosis instrument, diesel vehicle integrated diagnosis instrument. Factory Direct Sales (OBD connector) Vehicle diagnostic tool.
Details:
SPU: PSV502
Trade name: Fault code quick clearing; engine fault data flow reading card; elm327 fault detector; obd 2 diagnostic reading card; vehicle information reading card. Factory direct selling (OBD universal 16 PIN connector)
technical parameter
Master control chip: STM32F103VCT6 / APM32F103VCT6
Operating voltage: 9 36V
Operating current: 70-90 mA
Operating environment: -20 65℃
Storage temperature: -30 80℃
Overall dimension: 138.9 * 85 * 22mm
Packaging size: 200 * 130 * 43mm
Product weight: 265g
With packaging: 336g
Quantity quantity: 40 pcs
product description
1. Support the nine standard protocols for OBD II / EOBD.
2. Support the vehicle battery voltage test.
3. Support gasoline models to read; clear vehicle fault code; read data flow; freeze frame information; check MIL status; read vehicle information; oxygen sensor test; on-board monitoring (mode 6); evaporation system (mode 8) test.
4. Support fault code information query; with built-in about 40; 000 fault code library information.
5. Support data flow playback function; view / delete fault code; data flow and freeze frame information.
6. Support USB printing function; which can print fault code; data flow and freeze frame information.
7. Support for seven languages: English; Chinese; Italian; French; Spanish; German; and Russian.
8. Color screen display 2.8
9. Communication mode; OBD interface
10.CE/FCC/ROHS/UKCA Certification
Support agreement
1. SAE J1850 PWM (41.6Kbaud)
2. SAE J1850 VPW (10.4Kbaud)
3. ISO9141-2(5 baud init; 10.4Kbaud)
4. ISO14230-4 KWP (5 baud init; 10.4 Kbaud)
5. ISO14230-4 KWP (fast init; 10.4 Kbaud)
6. ISO15765-4 CAN (11bit ID; 500 Kbaud)
7. ISO15765-4 CAN (29bit ID; 500 Kbaud)
8. ISO15765-4 CAN (11bit ID; 250 Kbaud)
9. ISO15765-4 CAN (29bit ID; 250 Kbaud)
Reference Price (FOB)
1. Single product price; USD153.00
2.≥50set; USD91.80
3.≥100set; USD82.62
4.≥150set; USD74.36
5.≥200set; USD66.92
6.≥250set; USD60.23
7.≥300set; USD54.20
8.≥500set; USD48.80
Support one product one generation order business
More commodity specifications and preferential policies; welcome the letter to consult the business
